Help & InfoPayment PolicyShipping PolicyReturn PolicyFAQAbout UsNew List Item Engine Crankshaft 06H105021M For VW GTI EOS Tiguan Audi A3 A4 A5 A6 Q5 TT 2.0T USD 105.44 For Camshaft kit + Lifters + Head Gaskets 4.8L 5.3L 6.0L LS Cam 25-TSPCHOPacabra USD 331.66 ML3Z-17B968-AF For 2021- 2023 Ford F-150 Front Bumper Cover Lower Grille USD 30.00 HS55383 Cylinder Head Set with Head Bolt Kit For 13-19 Honda Accord 2.4L USD 60.00 Front LH Left CV Axle Assembly for BMW G30 530i 540i xDrive 2017-2019 2021-2022 USD 87.14 For Hendrickson Wide Bushing Installation Tool S-21307 Complete Kit
Cross References:
BWP HE9AA-T
Dayton 334-936
Euclid E-9575
Hendrickson S-21307
Meritor R309575
Sirco SH2034
Tiger Tool 15040
Removal of Bushing:
1.Scribe the bushing orientation on the beam tube and compression tube.
2.The spring pins are not required to line up with the bushing holes during removal.
3.Tighten retaining nuts to remove slack. Thread on hammer adapter in the event the bushing becomes seized. Hook up hydraulics and begin removal operation.
4.After each 2 inch stroke, re-tighten nuts to take up slack. (Most bushing will require 3-4 adjustments)
Installation of Bushing：
1.Lubricate the bushing and insert the bushing into compression cylinder.
2.Place the plunger on top of the bushing, align the mark on the bushing with the mark on the plunger. The 4 corresponding pins to the bushing type you are installing should seat into the bushing.
3.Tighten retaining nuts to remove slack. Thread on hammer adapter in the event the bushing becomes seized. Confirm the plunger is aligned with the scribed mark on the beam tube and the pins are still engaged in the bushing. Hook up hydraulics and begin installation operation.
4.After each 2 inch stroke, retighten nuts to take up slack. (Most bushing will require 3-4 adjustments)
Package Including:
1 Pc Bushing Installation Tool
Note:
1.This picture is of the Actual kit you will get.Please compare it to what you need to make sure it is the correct kit for you.
2.If you have any problems after receive the package, please contact us in time, before opening return or case.We will provide the best service for you.
