TECHNICS RS-1500 Vintage Reel To Reel – Professionally Restored– 1-Year Warranty For Sale

Akai GX-635D Custom Green Reel-to-Reel Tape Deck

Professionally Restored & Calibrated by HQaudios – Fully Tested – Tape & Hubs Included – Backed by Our 1-Year Warranty.

Fully Restored Custom Akai GX-635D

Offered here is a professionally restored Akai GX-635D reel-to-reel tape deck featuring a distinctive Custom Green finish.

This machine has undergone an extensive mechanical, electronic, and cosmetic restoration by our HQaudios technical team. The tape transport was serviced, key wear components were replaced, the electronic and audio sections were restored and calibrated, and playback and recording performance were carefully evaluated before final approval.

Every major operating function was verified, applicable moving components were cleaned and re-lubricated, and the machine completed an extended final test run to confirm reliable operation.

The tape reel and hubs shown with this machine are included with the purchase.

Key Highlights

Akai GX-635D stereo reel-to-reel tape deck
• Distinctive Custom Green finish
• Professionally restored and calibrated by HQaudios
• Mechanical tape transport extensively serviced
• Electronic and audio sections restored and calibrated
• Record and playback alignment professionally adjusted
• Akai GX head system
• 3-motor transport
• 6-head configuration
• Forward and reverse playback
• 3¾ IPS and 7½ IPS tape speeds
• Supports reels up to 10.5 inches
• Factory Multi-Voltage: 110 / 120 / 220 / 240V
• Tape & Hubs Included
• Actual photos of the machine being sold
• Video testing available
• 1-Year HQaudios Warranty

Professional Restoration & Calibration

This Akai GX-635D has been fully restored and professionally calibrated by our HQaudios technical team. Every major function was verified, mechanical assemblies were cleaned and re-lubricated where required, and electronic sections were inspected, measured, serviced, and adjusted for accurate and dependable operation.

1. Mechanical Restoration

• The transport mechanism was extensively disassembled and serviced, including the reel tables, capstan system, pinch roller assembly, and tension arms.
• Old lubricant, residue, and accumulated contamination were removed from applicable mechanical assemblies.
• Moving components were cleaned and re-lubricated using premium synthetic lubricant and damping grease where appropriate.
• New genuine pinch roller and drive belt components were installed.
• Brake bands were cleaned, inspected, and balanced for smooth and controlled tape stopping.
• Capstan and reel motors were cleaned, inspected, adjusted, and checked for proper operating torque.
• Reel movement, tape tension, fast-forward, rewind, forward playback, and reverse operation were tested extensively.

2. Electronic & Audio Section

• Aging capacitors in the power supply and signal-path sections were replaced as required with high-quality Nichicon and Panasonic components.
• Power-supply operation and audio signal paths were inspected and measured for stable performance.
• Bias and EQ circuits were professionally calibrated for both 7½ IPS and 3¾ IPS tape speeds.
• Calibration was performed using professional reference test equipment, including MRL test tape and oscilloscope measurements.
• Record and playback alignment was adjusted for accurate operation.
• Left and right channel levels were carefully matched, with channel balance calibrated to approximately ±0.2 dB during final setup.
• Logic relays and associated control circuits were inspected and serviced for dependable transport response.

3. Control System & Auto-Reverse Logic

• Switches, relays, contacts, and related control components were inspected and cleaned.
• Solder joints in serviced areas were inspected and reflowed where required.
• Transport controls were repeatedly tested in forward play, reverse play, fast-forward, rewind, stop, and record modes.
• Auto-reverse logic and the mechanical triggering system were extensively tested for consistent response.

4. Cosmetic & Control Restoration

• The machine was professionally cleaned and detailed throughout.
• The exterior was carefully finished in its distinctive Custom Green appearance.
• Knobs and controls were thoroughly cleaned and polished.
• VU meter illumination was renewed with warm-white LED lighting selected to retain a classic vintage appearance.
• The rear panel was thoroughly cleaned.
• RCA and DIN connections were cleaned and treated with DeoxIT to help maintain clean, low-resistance electrical contact.

5. Final QC & Extended Test Run

• Playback and recording performance were evaluated after restoration and calibration.
• Tape speed stability and transport behavior were checked at both operating speeds.
• Wow & flutter behavior, channel balance, meter response, and transport operation were evaluated.
• The machine completed a continuous 3-hour playback and recording test.
• Operating temperature and mechanical stability were monitored throughout the extended test.
• Fast-forward, rewind, forward playback, reverse playback, recording, and auto-reverse operation were confirmed before final approval.

Final Result

After restoration and calibration, this GX-635D delivers smooth tape transport, stable operating behavior, precise channel balance, and the clean, detailed presentation associated with Akai\'s respected GX head system. It is ready for collectors and serious analog enthusiasts looking for a professionally restored reel-to-reel deck rather than a machine that has received only a basic functional check.

Technical Specifications Model Akai GX-635D Track System 4-track, 2-channel stereo / monaural Maximum Reel Size Up to 10.5-inch reels Tape Speeds 7½ IPS and 3¾ IPS Pitch Control More than ±6% Heads 6 total – 2 GX record heads, 2 GX playback heads, 2 erase heads Motors 3 – 1 capstan motor and 2 reel motors Frequency Response – WR Tape 30 Hz–27 kHz ±3 dB at 7½ IPS
30 Hz–21 kHz ±3 dB at 3¾ IPS Frequency Response – LN Tape 30 Hz–25 kHz ±3 dB at 7½ IPS
30 Hz–19 kHz ±3 dB at 3¾ IPS Wow & Flutter Less than 0.03% WRMS at 7½ IPS
Less than 0.04% WRMS at 3¾ IPS Signal-to-Noise Ratio Better than 62 dB Channel Separation Better than 55 dB at 1 kHz Bias Frequency 100 kHz Inputs Microphone, Line, DIN Outputs Line, Headphone, DIN Power Requirements AC 110 / 120 / 220 / 240V, 50 / 60Hz – Factory Multi-Voltage Power Consumption 70W Country of Manufacture Japan Dimensions Approx. 17.4 W × 19.0 H × 10.1 D in
440 × 483 × 256 mm Weight Approx. 46.4 lb / 21 kg Factory Multi-Voltage Power

The original rear-panel power label on this exact machine confirms that it is a factory multi-voltage GX-635D.

It is rated for AC 110 / 120 / 220 / 240V, 50 / 60Hz with 70W power consumption. This is not a 120V-only version.

Tape & Hubs Included

The tape reel and hubs shown with this machine are included with the purchase. They complete the classic large-reel presentation of the GX-635D and allow the machine to be displayed as shown in our listing photographs.

Cosmetic Condition

This GX-635D has been professionally cleaned, detailed, and finished in a distinctive Custom Green color.

The custom finish gives this machine a unique appearance while maintaining the unmistakable design of the original GX-635D. Knobs, controls, meters, trim, rear panel, and exterior surfaces have also been carefully detailed.

As with any vintage component, minor signs of age or previous use may remain. Please review all photographs carefully, as they show the exact machine being offered and form an important part of the description.

Technical Condition

This machine has completed our full restoration, calibration, and final QC process.

Forward playback tested
• Reverse playback tested
• Recording tested
• 3¾ IPS operation tested
• 7½ IPS operation tested
• Fast-forward tested
• Rewind tested
• Auto-reverse operation tested
• Reel movement and tape tension tested
• Capstan and pinch roller operation inspected
• GX head system inspected and aligned
• VU meter response tested
• Channel balance calibrated
• Switches, relays, and transport logic tested
• 3-hour continuous playback and recording QC completed

Sound & Performance

The GX-635D is known for its robust large-reel transport, durable GX head technology, and detailed analog presentation.

After restoration and calibration, this example delivers smooth tape movement, stable playback, accurate channel balance, and the clean, open sound that makes the GX-635D a favorite among vintage tape enthusiasts.

Included With Purchase

Akai GX-635D Custom Green Reel-to-Reel Tape Deck
• Tape Reel
• Hubs
• 1-Year HQaudios Warranty

Actual Photos & Video Testing

All photographs in this listing show the actual GX-635D being offered for sale.

Detailed images are provided so you can closely review the Custom Green finish, tape transport, heads, controls, meters, rear panel, connections, and overall cosmetic condition.

Video testing has also been performed to demonstrate the machine operating and to provide additional confidence before purchase.

Professional Packing

Large reel-to-reel decks are heavy and mechanically complex, so proper packing is essential.

This GX-635D will be professionally packed by HQaudios with appropriate protection for the chassis, faceplate, controls, transport components, and exterior surfaces to help ensure safe transit.

1-Year HQaudios Warranty

Buying a professionally restored vintage reel-to-reel deck should come with confidence.

This Akai GX-635D is backed by our 1-Year HQaudios Warranty. We stand behind our restoration work and provide after-sale support should assistance be required.

A Special GX-635D for the Serious Collector

The Akai GX-635D is already one of the brand\'s most recognizable large-reel machines. This example combines that classic platform with extensive restoration, professional calibration, factory multi-voltage capability, a distinctive Custom Green finish, and included tape and hubs.
