Shars 10 - 15\" CNC BXA Wedge Quick Change Tool Post Set 250-222 New L} For Sale

Shars 10 - 15\" CNC BXA Wedge Quick Change Tool Post Set 250-222 NewInterchangeable with Dorian & Phase II Series

Suitable for lathe center heightAround1\" (The Top cross slideTool Post mounting surface to the lathe center line),such as:South Bend13\", 14\" & 1307,Delta14\",Logan14\" ,Emco: Elnomat13S ,Harrison: 11,12 &13\",Sheldon: 11 &13\" ,Clausing: 1300 series,Monarch: 13 ,Nardini: MS1400 MS1600Acer: 1340and many other importlathes.

Product code: SKU 202-9475C BRAND Shars Tool QUICK CHANGE TOOL POST CATEGORY Quick Change Tool Post Sets QUICK CHANGE TOOL POST SERIES BXA LATHE SWING 10-15 QUICK CHANGE TOOL POST TYPE Wedge NUMBER OF PIECES 6

HEX KEY SIZE 3/16” SET SCREW THREAD SIZE M10x19 Certificate for each batchProduct description:

• 250-222 Wedge Type Tool Post
• Lathe swing: 10\" -15\"
• Includes: 250-222 tool post holder, 250-201 holder, 250-202 holder, 250-204 holder, 250-207 holder, 250-210 holder
• Hex Key Size: 3/16\"
• Set Screw Thread Size: M10x19

Description:

• Made of high quality Alloy tool steel 40Gr which is forgedandhas longer life,not Aluminum.Precision ground and hardened
• Takes only a few seconds to change tools
• High quality 10.9 grade galvanized screwswhich have 1 time longer life than others
• Tool Post and Tool Holders No. 1, No. 2, No. 4, No. 7, No. 10
• No. 250-201 Turning Tool Holder ,use tool bit 1/4~ to 5/8\"
• No. 250-202 Boring,Turning Tool Holder, use tool bit up to 5/8\" andround shank boring bars up to1/2\"
• No. 250-204 Heavy Duty Boring Bar Holder, can use both 3/4 and 1\" shank boring bars
• No. 250-207 Parting Blade Tool Holder, use 11/16\" high parting blades
• No. 250-210 Knurling and Turning Tool Holder,use short tool bit 1/4~ to 5/8\"
• Wedge type tool posts are precision engineered to assure repetitive accuracy
• Advanced design provides built in quick tool changing versatility with positive rigidity to meet the most exacting working tolerances
• Quickly and easily installed on an engine, bench or turret lathe for a wide range of operations, from fine precise work to heavy duty cutting
• Maximum rigidity for chatter free performance
• Completely sealed for maintenance free operations
• Height adjustment screw allows accommodating various center height of different lathe chuck
• Manufacturedby anISO 9001certified manufacturer and come with an unique quality tracking number which can be tracked by the user

Product features

• Wedge type tool posts are precisely engineered to assure repetitive accuracy
• Advanced design provides built-in quick tool changing versatility with positive rigidity to meet the most exacting working tolerances
• Can be quickly and easily installed on an engine, bench or turret lathe for a wide range of operations, from precise work to heavy duty cutting
• This tool post comes with a blank T-slot nut plate. Customers will need to machine the plate to fit their own specific t-slot for their lathe.

Dovetail Dimensions:

• H: 0.417\"
• L1: 1.762\"
• L2 1.421\"

Relate Product Coarse Diamond Knurl

• 404-9324

• Medium
• Diamond
• Knurl

• 404-9325

• Fine
• Diamond
• Knurl

• 404-9326

Medium Straight Knurl

• 404-9291

Fine Straight Knurl

• 404-9292

11/16\" Retrofit GTN2 Cut-Off and Grooving Blades202-9576 11/16\" Retrofit GTN3 Cut-Off and Grooving Blades202-9577
