FEATURES
Sensor/ detection principle
Photoelectric proximity sensor, Background suppression
Dimensions (W x H x D)
15 mm x 49 mm x 41.5 mm
Housing design (light range max.
10 mm ... 1,000 mm 1)
Sensing range
80 mm ... 800 mm 1)
Type of light
Visible red light
Light style="color: rgb(85, 85, 85); font-family: Arial, Helvetica, sans-serif;">MECHANICS/ELECTRONICS
Supply voltage
10 V DC ... 30 V DC
Ripple
≤ 5 Vpp
Power consumption
≤ 30 mA 1)
Switching output
PNP
Switching mode
Light/dark switching
Response time
≤ 330 μs 2)
Connection type
Male connector M12, 4-pin
Housing material
Metal, Zinc diecast
Optics material
Plastic, PMMA
Enclosure rating
IP67
Ambient operating temperature
–40 °C ... +60 °C
Ambient storage temperature
–40 °C ... +75 °C
UL File No.
NRKH.E181493 & NRKH7.E181493
