Parker Hannifin 230R2 / 230RM2 Fuel Fltr/Wtr Separator.
Shipsfrom Oregon the day you order it.
ParkerLogo
Fuel Filter Water Separator – Racor Spin-on Series
Part #: 230R2
Diesel Spin-on 200 Series filter with: (Pump) Hand Plunger Priming Pump, (Heater) No Heater, (Bowl) Clear Engineering Plastic, (Element) 2 Micron Aquabloc Spin-on.
View Series PageView Catalog(s)
Share / EmailPrint
Technical Specifications
Flow Rate:30 gph (114 lph)
Bowl Material:Clear Engineering Plastic
Part Type:Filter Assembly
Mounting:Bracket Included
Product Series:Diesel Spin-on 200
Heater Power Rating:No Heater
Integral Primer Pump Included:Hand Plunger Priming Pump (Diesel or Gasoline)
Bowl Type:Standard, Clear Engineering Plastic
Micron Rating:98% @ 4 Micron
Product Type:Diesel Spin-on FF/WS
Location:North America and EMEA regions
Brand:Racor
For Fluid Type:Diesel and Gasoline
Clean Pressure Drop:0.31 psi, 2.14 kPa
Compatible Element:R20S = "2" Micron
R20T = 10 Micron
R20P = 30 Micron
Filter Element Type:2 Micron Aquabloc Spin-on
Height:9 inch, 229.0 mm
Width:4 inch, 102.0 mm
Depth:4 inch, 102.0 mm
Weight:2 lb / 0.90 Kg
Head Material:Aluminium Alloy
Accessories Included:See Product Support Tab
Maximum Operating Pressure:30 psi, 207.0 kPa
Number of Ports:1 Inlet / 2 Outlet
Operating Temperature:-40 to 250 °F, -40 to 121 °C
Maximum Fluid Temperature:190.0 °F, 88.0 °C
Port Size:1/4" NPTF
