****These pumps are New Open Package with a few small scratches and nicks from being stored. Never Used.
The Lubriquip Modu-Flo AL-5 Pneumatic Pump (Part/MPN # 521-000-001) is a modular, single-acting pneumatic pump designed for oil or grease applications in series progressive centralized lubrication systems. It is a heavy-duty, series-progressive pneumatic lubrication pump.
Technical Specifications
Pump Model: AL-5 / AL-5M
Pump Type: Single-acting Pneumatic (Air-operated)
Pressure Ratio: 30:1 air-to-lubricant pressure ratio
Output: Adjustable stroke output for easy system customizing.
Adjustable Output: 0.010 to 0.030 in³ per stroke (0.164 to 0.492 cc).
Mounting: Modular design that mounts to standard Modu-Flo pump-to-reservoir manifolds without disconnecting lubrication lines.
Compatibility: Configured for series progressive oil or grease systems.
