[ INTEL ARDUINO2.AL.B Edison Board for Arduino* 70-pin Hirose .4mm]
ABOUT THIS ITEM
KEY FUNCTION WORKING
UI:[ V002508]
**[ New]**
INCLUDES: [1 x Board]
FEATURED DESCRIPTION:
🔧 Intel Edison – ARDUINO2.AL.B Adapter Board (70‑pin Hirose, 0.4 mm pitch)
The ARDUINO2.AL.B is an Intel Edison Arduino Breakout Board, sometimes referred to as the Edison Arduino Expansion Board. It was designed to mate with the Edison compute module using the 70‑pin Hirose board‑to‑board connectors (0.4 mm pitch).
🧩 Key Technical Details
✅ Connector
Uses dual 70‑pin Hirose DF40 series connectors
0.4 mm pitch, board‑to‑board mezzanine style
Mates with the Edison module’s bottom connectors
✅ Function
Adapts the Edison to an Arduino Uno‑compatible footprint
Breaks out:
GPIO
UART
SPI
I²C
PWM
USB OTG
Power rails (5 V, 3.3 V, VIN)
✅ Board Features
Standard Arduino R3 header layout
DC barrel jack input
USB device and host ports
Level shifting for Arduino‑compatible I/O
Power regulation for Edison module
Micro‑USB for programming and serial console
