Endress+Hauser Cerabar S PMP71 digital pressure transmitter. Removed from service and bench-tested working.Powered up on a 24V DC supply — the local display reads a live process value (-1 psi at atmospheric, normal zero offset for a gauge sensor at rest; see photos). LCD is fully functional with no dead segments. Electronics and sensor cell both confirmed operational.Nameplate specs: • Order Code: PMP71-SBC1W61RDAAA
• Serial: F8014C1509C
• Max Working Pressure: 6000 psi
• Range: -15 to 6000 psi (Cal/Adj 0–6000 psi)
• Output: 4–20 mA HART, 11.5–30 V DC, loop powered
• Wetted material: 316L stainless (1.4435/316L)
• Process connection: 1/2" MNPT
• Enclosure: NEMA 4X/6P
• Approvals: FM Intrinsically Safe — Class I Div 1 ABCD / Class II Div 1 EFG / Class III, Zone 0 AEx ia IIC T6
• Assembled in USACondition: Used field unit. Cosmetic wear consistent with oilfield service — faded housing paint and surface rust on the covers. Conduit entry threads show rust (does not affect operation). Process diaphragm and threads are clean. Sold as tested/working; no returns based on cosmetics.Loop-powered — no battery required. Comparable new units configured this way run over $1,800.
