Bussmann JT60030 Fuse Holder:
$30.00
Bussmann JT60030 Fuse Holder
PN: JT60030
The Bussmann JT60030 is a Class J fuse holder with a voltage rating of 600 VAC/600 VDC and a current rating of 30 Amps. It is made of thermoplastic and measures 1.230 Inch x 2.520 Inch x 2.750 Inch. The fuse holder has a neon indicator with a voltage rating of 90 VAC/115 VDC and an interrupt rating of 200 kilo-Amps. It is UL listed and CSA certified.
GENERAL SPECIFICATIONS
- PRODUCT NAME: Eaton Bussmann series JT finger-safe fuse holder
- CATALOG NUMBER: JT60030
- PRODUCT LENGTH/DEPTH: 2.52 in
- PRODUCT HEIGHT: 2.75 in
- PRODUCT WIDTH: 1.23 in
- PRODUCT WEIGHT: 0.233 lb
- COMPLIANCES: RoHS Compliant
- AMPERAGE RATING: 30 A
- VOLTAGE RATING: 600 V
PHYSICAL DETAILS
- MATERIAL
- Thermoplastic
- OPERATING TEMPERATURE - MAX
- 75 °C
- OPERATING TEMPERATURE - MIN
- 75 °C
GENERAL INFORMATION
- CLASS: Class J
- CONNECTION: 18 to 8 AWG tin plated copper alloy terminal
- MOUNTING METHOD: 35 mm DIN rail
