The Akai GX-630D is a highly regarded, 3-head, 2-track direct-drive stereo tape deck introduced in the mid-1970s. It is universally praised by vintage audio enthusiasts for its legendary, virtually indestructible GX (glass and crystal ferrite) heads, robust mechanical build and warm, inviting classic analog sound.As per Akai advertisements at the time, you could run an Akai GX series deck 24/7 for 17.5 years before they wore out. That\'s 150,000 hours, as compared to a more typical 3000-4000 hour life span of steel reel to reel heads of the 70-80\'s.
We post an actual video demo to show the superior quality of this unit in recording and re-playing compare to digital source.Please pay attentionat the time I toggle between digital music source and re-recorded music(Tape/Source button). You could hear the different between harsh Digital sound and sweet Analog due nature harmonic distortion of tape. As results, the recorded music on tape introduces pleasing vocal tone and saturation - while adding richness and fullness, especially to bass frequencies, that digital music and streaming media often lacks.
Service Notes
We acquitted this unit from original owner and bring to our shop for full service and re-calibration to factory specifications as recommended in service manual. Our technicians painstakingly check every capacitors for sign of leaking or degrading. We also usedspectrum analyzerto measure noise floor of the unit - to ensure no noisy and/or pin corrosion transistors on both pre-amplifier and recording board. All suspected faulty or degraded electronics components were searched and replaced as needed.
After playback calibration and bias setup, we apply signal generator to measure and calibrate the record level as factory specs. All tape play and record from line-in and microphone are also bench tested for sound and reproduction quality. All switches, pods, tires, tension wheels, reel brakes and tape transport mechanism are thoroughly checked, serviced and replaced when necessary.
Play heads and metal parts on the tape track are demagnetized and cleaned. The deck also tested for tape tracking, speed (wow and flutter using Meguro MK-668) record balance and reading from both microphone and line-in.
Finally, we produced a demo video to showcase the quality of this unit as it records and replays one minute of digital music directly from CD to reel tape. You can hear the demo for yourself - or, better yet, plug in a pair of headphones to experience the unit’s superior music reproduction quality.Vintage Sound Preservation Notes
“Vintage Wine Sommeliers”: At our private shop, our technicians are not only skilled in electronics but also dedicated vintage audiophiles who also take on the role as Sommeliers. We are committed to preserving the distinct sound qualities of the vintage equipment we service, steering clear of unnecessary component replacements or upgrades. In the other words, we ensure that vintage Bordeaux wine would never be replaced or watered-down with contemporary California wine.
“Old-Time Sweet, Softness and Mellow Tones” Preserving: When modern transistors replace the aged ones in these classic machines, the sound can sometimes come across as \"too clean\" or “overly sterile” for those who love the sonic characters of traditional components. To honor this vintage essence, we focus on carefully preserving or replacing those specific Field-Effect Transistors (FETs) and/or MOSFETs that are integral to the signal path, ensuring that we maintain those beloved audio signal response curves - that define vintage sound.\"Vintage Warmth\" Preservation: Degraded capacitors naturally roll off high frequencies and create signal harmonic smearing. This artifact is often misidentified as \"analog warmth.\" New replacement caps would bring back sharp treble and fast transients, which can sound surprisingly harsh or bright. We never simply replace capacitors with the same maker’s value in critical audio paths. Instead, we meticulously measure the remaining value of each working capacitor on the board and replace them with exact matches in pairs for stereo channels—or in sets of four for quadraphonic machines.Technical Notes
The listing is for a tape deck unit, specs sheet and owner manual only. NO reel, No tape, No hub, No remote, No Box, No Cable, No Microphone, No other accessories included.
The unit is in good cosmetic condition - No blemishes on the face plate but would need a good polishing/cleaning. The machine shown signs of previous usage such as surface scratches, small dings, fade out color spots, sticker residues, stains, worn-out corners and edges on the case, especially the wooden side boards and the bottom. Photos are part of the descriptions. See photos and video for details.Due to the fact that most tape reels you have or available on themarket right now were more than 50 years old - we would recommend you record music (or tape remaster) and play back reel tape on the same machine. The use of degraded pre-recorded music reel tapes would be used with consideration. The frequently cleaning the play head each use would be needed to ensure the best sound quality also.
For professional re-master or record quality, we would recommend a pre-amplifier or even an audio mixer setup between the source and the tape recording - for better control of sound balance, tone and level for each of two channel.
If you happen to have sticky old reel tapes (especially two-tone tape), you would consider pre-bake the tape or recondition it before play on this machine. The reel motors on FF or RW mode will slow-down or even stop in operation withsticky / degraded reel tapes.
Operate on 100-240V / 50/60Hz - Currently preset at U.S. Domestic 120V/60Hz.
No reverse play. Only directional play and record with 3-Motor 3-Head Tape mechanism. Features 4 track, 1/4\" Width Tape, 2-channel, stereo system. Single capstan tape drive.
Shipping Note
Will ship the 41lbs unit with fully insured carrier, packed in dual walled carton (up to 50 lbs totally) with double 1\" thick Styrofoam insulation and all corner reinforced.Buyer direct signature is required by both and Carriers due to Buyer protection policy. No meet in person - No delivery.
Flat rate $40 expedite shipping to anywhere in the U.S to residential address only. No P.O Box. International and U.S. territories buyers please contact Seller first.If you happen to be a local to Los Angeles Metro, you are more than welcome to contact us by message to stop by and audition the item prior to buying. No shipping charge and a great 10% discount will be given for local buyers only.New buyer with zero/no response please contact before buying. We reserve the right to cancel the sale to anyone.
No return if due to buyer mishandling or damage because of lack of proper operational knowledge - and above all we are watching out for the part swappers if anti-tamper stickers on the unit removed or broke off. Serial number is photographed and recorded.
Shipping carriers will be selected by Seller to ensure the best logistically and timely delivery to Buyers.Please allow two business days for packing and shipping.
Specifications
Track system: 4-track, 2-channel, stereo/monaural system
Heads: 1 x playback, 1 x record, 1 x erase
Motor: 2 x reel drive, 1 x capstan
Reel size: up to 10.5 inch reel
Tape speeds: 3 3/4 and 7 1/2 ips
Wow and flutter: 0.06% (7 1/2 ips)
Frequency response: 30Hz to 25kHz (7 1/2 ips)
Signal to Noise Ratio: 57dB
Total harmonic distortion: 0.5%
Input: 70mV (line), 2.5mV (DIN), 0.25mV (mic)
Output: 0.775V (line), 30V (DIN)
Semiconductors: 50 x transistors, 57 x diodes
Dimensions: 465mm (18.3\") x 440mm (17.3\") x 240mm (9.4\")
Weight: 19kg (41 lbs)
Year: 1976
