Soviet Car Chassis Atlas: 1977
The Definitive Technical Engineering Manual of the USSR
➼ ASK ABOUT COMBINED POSTAGE ON TECHNICAL BOOKS!
On offer is a substantial and rare piece of automotive history: the 1977 Car Chassis Atlas (Шасси автомобиля – Атлас конструкций). Authored by esteemed engineers V.B. Tsimbalin, I.N. Uspensky, V.V. Konyashov, and others, this large-format atlas was the primary educational resource for university-level mechanical engineering in the Soviet Union.
Published by the state enterprise Mashinostroenie (Машиностроение), this volume contains 110 pages of high-fidelity technical illustrations, schematics, and design methodology. It provides an exhaustive look into the suspension, braking, and steering systems of iconic Soviet vehicles, ranging from passenger cars like the Moskvich and Volga to heavy-duty KrAZ and MAZ trucks.
Featured Vehicle Schematics:
- GAZ (ГАЗ): 21Б, 24, 13, 51А, 52, 53А, 66
- ZIL (ЗИЛ): 130, 118, 111, 114
- LiAZ (ЛиАЗ): 677
- Ural (Урал): 375
- MAZ (МАЗ): 502, 500А, 500, 527, 503
- KrAZ (КрАЗ): 219
- Moskvich (Москвич): 408, 412
- ZAZ (ЗАЗ): 965, 966
- VAZ (ВАЗ): 2101
Technical Specifications:
- Title: Шасси автомобиля – Атлас конструкций (Car Chassis – Atlas of Constructions)
- Year: 1977 (USSR)
- Publisher: Mashinostroenie (Машиностроение)
- Authors: V.B. Tsimbalin, I.N. Uspensky, V.V. Konyashov et al.
- Language: Russian (Русский язык)
- Format: Large Boardcover / Hardcover
- Page Count: 110 + 4 covers
- Print Run: 24,500 copies
- Condition: Very Good vintage condition. Light wear on cover corners; interior pages are clean and complete. See photos.
Dimensions: Attribute Metric Standard Size42 cm x 27 cm16.5 in x 10.6 in Weight780 g1.7 lbs
Краткое описание: Атлас конструкций шасси автомобиля, 1977 год. Издательство «Машиностроение». Подробные чертежи, схемы и расчеты легковых и грузовых автомобилей СССР. Отличное коллекционное состояние.
Authentic Engineering Reference • Professionally Packed • Worldwide Tracking
