U.S. Motors Nidec 48 Y-Frame Square Flange Swimming Pool Pump ASQ125
SKU: Motors Nidec 48 Y-Frame Square Flange Swimming Pool Pump ASQ125
SKU: 38652 Item Description The Nidec 48 Y-Frame Square Flange motor is a powerfully designed motor for your pool or spa. Its Triple Bearing Protection prevents premature wear and tear and its sealed ball bearings provide additional support giving you long lasting performance. The Nidec 48 Y-Frame Square Flange motor features a smaller 48 frame size and has an open drip proof enclosure that keeps water from flowing into the motor. It also has a rear mounted fan that keeps the motor cool during operation. The Nidec 48 Y-Frame Square Flange is a single speed pool and spa motor with up-rated 1-1/2\"HP, giving it the capability to perform at higher standards for maximum power.
- Two compartments
- Shaft Threads 1/2-20 UNF-2A
- 50 Degrees Celsius Ambient
- 1081 Design
- Continuous Duty
- Voltage Selection Device (Dual Voltage Only)
- Service Factor: 1.04
- RPM: 3450
- 8.5/17.0A 115V/230V
- Length without Shaft: 12.28
Installation Instructions:
- Ensure the pool motor is compatible with your pool pump.
- Turn pump power off during replacement.
- Check voltage requirements on your current setup.
- Always replace the mechanical pump seal. It\'s recommended to replace all gaskets when replacing the motor.
- Turn on the pump to test for leaks and pump operation.
- Please reference additional installation instructions in owner\'s manual in Guides and Documentation section below.
- Please Note: We recommend professional installation or the manufacturer warranty may be void. See Warranty section below.
