Supermicro 16-Port 12G SAS-3 SATA AOC-S3916L-H16iR-32DD SAS3 Raid Controller For Sale

Wenn nicht gesondert in der Artikelbeschreibung angegeben, ist der Artikel gebraucht.

Jedes Gerät wird vor Veröffentlichung des Angebotes und vor dem Versand von unserem Fachpersonal ausgiebig geprüft und gegebenenfalls instandgesetzt.
Der Artikel ist gereinigt, kein Staub, keine sonstigen Verschmutzungen. Bei einem gebrauchten Artikel können normale, übliche Gebrauchsspuren vorhanden sein. Wenn Sie eine Änderung und/oder weitere Upgrades oder zusätzliche Erweiterungen wünschen muss dies in der Kaufabwicklung mit angegeben werden. Auf anderen Kommunikationswegen mitgeteilte Änderungswünsche am Lieferumfang werden nicht berücksichtigt.

Lieferumfang: Supermicro Broadcom AOC-S3916L-H16iR-32DD 8GB 9560-16i PCIe 4.0 2x SFF-8654 HDD SSD Controller Raid 0, 1, 5, 6, 10, 50, 60 incl. BBU

12 Monate Gesetzliche Gewährleistung für Verbraucher nach BGB.
Ort für den Gewährleistungsanspruch ist der Standort des Verkäufers. Instandsetzung erfolgt in den Räumen des Verkäufers. Der Käufer trägt die Kosten für den Transport zum Standort des Sie nicht, uns bei weiteren Fragen jederzeit direkt zu kontaktieren.

• SERVERSCHMIEDE.COM GmbH
• Kontakt Telefon
  E-Mail
  Fax

incl. VATTechnical data:Vendor / OEM: Supermicro | Broadcom Model: PN: AOC-S3916L-H16iR-32DD RAID Controller: AOC-S3916L-H16iR-32DD BBU Kabel: CBL-PWEX-0937P-62 BBU: Broadcom FBU345 49571-22 Controller Type: Storage internal SAS Formfactor: Full or Low Profile (configurable) Host Bus: PCIe x8 Interface: 2x SFF-8654 8i 12 Gb Cache: 8GB RAID Level: 0, 1, 5, 6, 10, 50, 60 Net weight: 0,227 kg Dimensions: L: 16,8 cm | B: 7 cm | H: 1,5 cm Broadcom 3916 2xSFF-8654 x8 max. 32 devicesPCIe Slot: PCIe 4.0 x8
Ports: 16 (intern)
Connectors: 2x SFF-8654 x8
Cache Protection (optional): BTR-CVPM05
Cache Memory: 8GB DDR4-2666
RAID-on-Chip Controller: Broadcom SAS3916 / ARM A15 @ 1.6 GHz
Power Consumption: 18W
Formfactor: Full-Height & low profile Max. Devices Supported: SAS/SATA: 8 Direct Attached / Up to 32 w/ Expander
RAID Level Support: Raid 0, 1, 5, 6, 10, 50, 60, JBOD ModeLow profile x8 PCIe Gen 4.0 root complex interface
8GB DDR4 onboard cache memory – 2666MHz
Power consumption: 14 Watts for AOC-S3908L-H8iR & 18 Watts for AOC-S3916L-H16iR
Supports 3.0, 6.0 and 12.0 Gb/s SAS data transfer rates and 3.0 & 6.0 Gb SATA
Support for MCTP over I²C/PCIe
Cachevault to protect onboard cache memory
Supercap - BTR-CVPM05 (Optional)
TFM – Included on-board
Supports advanced software Encryption - included
Supports in LSA Storage Authority Software WebGUI
Secure boot
UEFI Configuration utility
OS Support: Windows/Linux
Dimensions: 2.71\" x 6.6\" (H x L)
Thermal operating range: System dependent (55°C or higher w/ enough airflow) Item condition: refurbished, Grade A. The item has been completely tested / refurbished.Item condition/Shipping

Wenn nicht gesondert in der Artikelbeschreibung angegeben, ist der Artikel gebraucht.


Technical condition: No technical flaws. The article has been checked by our professionals before publishing.
Optical condition: The server is secondhand and doesn\'t show optical flaws. The article is cleaned, no dust or anything. Only normal signs of usage.
Memory devices have been formatted if not displayed otherwise. Latest free available firmware has been flashed on system bios, storage controller, network controller and management controller. If you wish any changes, upgrades or other expansions please note at . We can\'t consider requests concerning delivery contents via other ways of communication.

Delivery: Supermicro Broadcom AOC-S3916L-H16iR-32DD 8GB 9560-16i PCIe 4.0 2x SFF-8654 HDD SSD Controller Raid 0, 1, 5, 6, 10, 50, 60 incl. BBU

Delivery is as described, without further accessories, without manuals, without data carriers, exclusively as described. Please read carefully before buying the item description to avoid inconvenience in the aftermath. In case of doubt, we ask you to ask your questions before buying to avoid inconvenience in the aftermath.
For example: If the article description says: \'CPU Processor: default: without CPU \' Does this mean that without their selection no processors are included. Please do not assume any accessories that are not explicitly listed in the item description or in the scope of delivery.
Please bear in mind, as far as this article is a used, refurbished article, the equipment of the delivery may differ from that of a new device. Warranty

12 month warranty required by law for customers according to German Civil Code. Place of warranty claim is the location of the seller. Repair will be effected in the sellers business premisses. The customer covers the cost of the transport to the location of the seller.
