New Schlage M452P Double Electromagnetic Lock Mag Lock:
$449.00
Includes Magnetic Bond Sensor, Door Position Switch, Relock Time Delay
All M452 Series locks have automatic voltage sensing for 12 and 24 volts along with polarity protection to make wiring less complex. The M420 is tested and certified to meet or exceed UL1034 and BHMA 1000lb. hold force requirements.
Standard Features
- 1000lbs Holding Force per leaf
- Auto voltage selection 12/24VDC
- Bayonet Mount makes installation simpler
- UL1034 Burglary-Resistant Electronic Locking Mechanisms, UL10C Positive Pressure Fire Tests of Door Assemblies and ANSI/BHMA A156.23 Grade 1 certifications
- Limited Lifetime Warranty
Model
- M452 - Standard Double 1000lbs holding force magnetic lock
- M452P - Includes Magnetic Bond Sensor (MBS), Door Position Sensor (DPS), Relock Time Delay 0.5 to 30secs(RTD)
Mechanical Specifications
- Holding Force:1000lbs per leaf
- Lock:20-9/16 inches L x 3 inches H x 1-3/4 inches D
Eletrical Specifications
- Voltage:12/24VDC, Automatic voltage sense
- Current:1.5A @ 12VDC; .750A @ 24VDC
