We conducted extensive research when customizing molds and found that, different ATVs may have varying wiring sequences for high beam, low beam, and ground (negative). This is a difference in factory configuration, not a problem with the product itself. Since we cannot cover all configurations, we provide an adapter cable. Some model( eg. 2008、2009、2023+ YFZ700/YFZ450) will need to modify wire harness, package include the adapter cable. Professional installation is highly recommended.PACKAGE INCLUDE:
1 X Pair LED Headlights with DRL and Turn Signal for Yamaha ATV Raptor(Both Right and Left Sides)SPECIFICATION:2PCS LED headlights for Yamaha Diameter:188mm/ 7.4inch Depth:210mm/8.2 inch Color Temperature:6000K Voltage: DC 12V Power: 32W@High Beam, 12W@Low Beam Lumen: 3200lm@High Beam1200lm@Low Beam Outer Lens Material: PC Housing Material: PC＋ABS Function: High Beam & Low Beam & DRL & Right/Left Turn Signal
FEATURES:
Product Certification--The Headlight carries the European Union\'s E24-mark and the DOT certification guarantee your lights are Compliant in the United States Department of Transportation for use in the U.S. & Canada & Australia to secure the safety of others.
Safe Driving--The response speed of LED lights is faster than halogen lights, and it have ultra-high brightness and ultra-wide field of view, so the driver can drive freely in the dark without worrying about driving problems caused by the darkness of the road.
Excellent Heat Dissipation System--Lightweight, only one-third of the weight of a cast iron radiator with the same heat dissipation capacity. Safe and reliable, with high thermal efficiency, good thermal conductivity, energy conservation and environmental protection, and long service life.
Easy Installation--Just Plug and Play. Complete set Headlight are designed to simply plug into your existing wiring without any cutting or drilling. Some model( eg. 2008、2009、2023+ YFZ700/YFZ450) will need to modify wire harness, package include the adapter cable.
DRL Wiring Installation Tips(3 methods):1. Splice the white DRL wire to brown low beam wire, in this way DRL will work with low beam on.(Need some modification skills)2. If you want to control the white DRL individually, you will need to splice it to the main switch or use an extra on/off switch harness. Splicing to main switch is simple, find the positive cable and splice the white cable to it. But not highly recommend this method since we don\'t know how much you know about your bike electric. You can contact us for the purchase link.3. Please use a Fuse Tap(10/20A) and tap it into the fuse box (Ignition/Cigar lighter fuse or other Fuse). Package not include fuse tap.This way DRL will always on as your Bike is activated. Package is not include the fuse.Turn Signals Indicator Light:Yellow wire is the turning blinker, you need to purchase a wiring harness separately to install it. We do not sell it separately, but we can recommend a link for you. Note that the turn signal does not affect the use of high beam/low beam/DRL, it is an independent wiring harness.
FITMENT:For Yamaha Raptor 250 YFM250R 2008-2013For Yamaha Raptor 250 Special Edition 2008/2009/2011For Yamaha Raptor 350 YFM350R 2004-2013For Yamaha Raptor 350 Special Edition 2007For Yamaha Raptor 700 YFM700 2006-2008/2013-2025For Yamaha Raptor 700 Special Edition 2007-2012For Yamaha Raptor 700 50TH ANNIVERSARY 2006For Yamaha Raptor 700 GYTR EDITION 2007For Yamaha Raptor 700R YFM700R 2011-2012/2016-2025For Yamaha Raptor 700R Special Edition 2013-2025For Yamaha Raptor 700 R 2009For Yamaha YFZ450 2004-2009/2012-2013/2017For Yamaha YFZ450 Special Edition 2005-2008For Yamaha YFZ450 Special Edition II 2008For Yamaha YFZ450 Limited Edition 2004For Yamaha YFZ450R 2009-2016/2018-2025For Yamaha YFZ450R Special Edition 2009-2025For Yamaha YFZ450X 2010-2011For Yamaha YFZ450X Special Edition 2011For Yamaha YFZ450V 2006For Yamaha Wolverine 350 YFM350X 2006-2009For Yamaha Wolverine 450 YFM450FX UsresponsePayment
