Ignition CDI Module 2008-2011 Rhino 700 YXR700F 686cc 5B4-8591A-01-00
Replaces Part Numbers & Specifications
OEM PART NUMBERS:
• Yamaha: 5B4-8591A-01-00 / 5B48591A0100 (current)
• Yamaha: 5B4-8591A-00-00 / 5B48591A0000 (superseded by 5B4-8591A-01-00)SPECIFICATIONS:
• Type: CDI Module (Capacitor Discharge Ignition) / Engine Control Unit
• Ignition System: 32-Bit ECU / TCI (Transistor Controlled Ignition)
• Engine: 686cc Liquid-Cooled 4-Stroke Single Cylinder SOHC 4-Valve
• Bore x Stroke: 102.0mm x 84.0mm (4.02" x 3.31")
• Compression Ratio: 9.2:1
• Fuel Delivery: Yamaha Fuel Injection (YFI) with Mikuni 41mm Throttle Body
• Starting: Electric with Auto Decompression
• Weight: 0.69 lbs (0.31 kg)
• Condition: NewAPPLICATION:
• Rhino 700 FI YXR700F 4x4 Auto / Sport / Special Edition (2008-2011)
• All Rhino 700 YXR700F 686cc fuel injected variants (2008-2011)Ignition CDI Module — 5B4-8591A-01-00
New ignition CDI module for 2008-2011 Rhino 700 YXR700F 686cc fuel injected side-by-side UTV. Direct replacement for Yamaha 5B4-8591A-01-00 and 5B4-8591A-00-00. 32-bit ECU with transistor controlled ignition system for the 686cc liquid-cooled SOHC 4-valve engine. On-Command 2WD/4WD/4WD diff lock with Ultramatic CVT transmission.
Product Notice
As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.
