The EvolutionGear OGL is a compact laser aiming and infrared illumination module featuring a clean VCSEL IR illuminator with adjustable divergence and consistent illumination.
Fully PCB potted and epoxy sealed to improve internal component protection, shock resistance, and long-term performance under recoil and demanding conditions. The OGL is engineered for the shock and vibration associated with real-world use and features genuine US-made IR laser and illuminator modules for reliable performance. Fully IPX7 waterproof for unmatched durability.
Features
- CNC-machined 6061 aluminum housing
- VCSEL IR illuminator
- Adjustable IR illumination with wide divergence range
- Ergonomic IR illumination adjustment lever
- Rear mode selector
- Functional IR illuminator diffuser cap included
- Fully PCB potted and epoxy sealed
- Positive-click windage and elevation adjustments
- Hard-anodized finish available in Black or FDE
- Picatinny mounting interface
- Crane connector
- Compatible with Crane-style remote switches
- IPX7 waterproof construction
- Manufactured by EvolutionGear
- One-year limited warranty
Specifications
Laser
- Co-alignment precision: ≤1 MOA
- IR wavelength: 850 nm
- IR laser power: 0.6mW / 40mW
- IR beam divergence: 0.5 mrad
- Visible laser wavelength: 650 nm / 520 nm
- Visible laser power: 4.5mW / 40mW
- Visible beam divergence: 0.5 mrad
IR Illuminator
- Type: VCSEL IR laser
- Wavelength: 830 nm
- Power: 10mW / 200mW High
- Adjustable divergence: 15–150 mrad
Housing: CNC-machined 6061 aluminumFinish: Black / FDEMounting interface: PicatinnyBattery: 3V CR123AConnector: CraneRecoil Rated Up to .308Waterproof rating: IPX7Warranty
1-Year Limited Warranty — Manufacturing Defects Only
This product includes a one-year limited warranty covering manufacturing defects.
The warranty does not cover damage caused by water, dust, dirt, misuse, improper handling, human error, normal wear and tear, modifications, or unauthorized repairs.
Returns
30-Day Free Returns
We offer free 30-day returns. If you experience an issue with your order, please contact us before opening a formal return request so we can work with you to resolve the issue as quickly as possible.
