DVB ASI TS Stream 1x4 Distributor/splitter For Sale

DVB ASI TS Stream 1x4 Distributor/splitterOutlineCEL-7103 DVB ASI TS Stream 1x4 Splitter is a special device used to divide an input of 1 route ASI signal into outputs of 4 routes ASI signal with no need of decompression or re-process. Input stream from digital satellite receivers, encoders or multiplexers can be distributed as 4 routes through this unit directly. So this device is widely applied in the field of digital television broadcasting.FeaturesTwo routes input stream with individual monitoring，one work and one backup;Be sure to pull out power plug when unit will not be used for a long period. Do not use any broken socket to avoid fire or electric shock.Do not touch socket with wet hands which may lead to electric shock.Be sure to pull out plug but not wire while disconnecting.Do not drop any inflammable, metal or liquid object inside for which may break this unit.Do not place this unit near any heat source as radiator or hot ducts or any places exposed to direct sunshine, dusty or mechanical vibration.Keep this unit working in an adequately ventilated environment otherwise destruction may occur.Keep original packaging in good store for further safe transportation.

Performance index

ASI Input port

Socket: BNC

Impedance: 75Ω

Package format: 188/204 byte(Optional)

Data speed: 270Mbps

Standard: DVB

ASI Output port

Socket: BNC

Impedance: 75Ω

Package format: 188/204 bytes(Optional)

Data speed: 108Mbps

Standard: DVB

Port

No. of plug in port

2 Route (1 used and 1 backup)

Input port

DVB ASI

No. of output port

4 route

Output port

DVB ASI

Port features

ASI

DVB standard

Data speed

2~108Mbps

Property

Size

93mm×153mm×42mm

Environment

Power

110V/220VAC±10%,50Hz

Weight

1Kg
