ASUS PRIME Q370M-C LGA1151 MOTHERBOARD 9th/8th Gen CPU with IO Shield (TESTED) For Sale

*** No CPU, no RAM, no Heatsink/Fan ***

ModelPRIME Q370M-CCPUIntel® for 9th/ 8thGeneration Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Supports Intel® 14nm CPU
Supports Intel® Turbo Boost Technology 2.0
* The Intel® Turbo Boost Technology 2.0 support depends on the CPU types.ChipsetIntel® Q370Memory4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Supports Intel® Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* The maximum memory frequency supported varies by processor.
** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.GraphicIntegrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : HDMI/RGB/DisplayPort ports
- Supports HDMI with max. resolution 4096 x 2160 @ 24Hz / 2560 x 1600 @ 60Hz
- Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
Maximum shared memory of 1024 MB (for iGPU exclusively)
Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™
Supports up to 3 displays simultaneouslyExpansion Slots1 x PCIe 3.0/2.0 x16
2 x PCIe 3.0/2.0 x1
1 x PCIStorageIntel® Q370 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (x4 PCIE mode)
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel® Optane™ Memory ReadyLANIntel® I219LM, 1 x Gigabit LAN Controller(s)AudioRealtek® ALC8878-Channel High Definition Audio CODEC *1
- Supports : Jack-detection, Front Panel Jack-retaskingUSB PortsIntel® Q370 Chipset :
4 x USB 3.1 Gen 2 port(s) (4 at back panel, , Type-A)
Intel® Q370 Chipset :
4 x USB 3.1 Gen 1 port(s) (4 at mid-board)
Intel® Q370 Chipset :
4 x USB 2.0 port(s) (2 at back panel, , Type-A, 2 at mid-board)Special FeaturesTPM IC Onboard
Bespoke Motherboard Design & Business Focused Features :
- ASUS Self Recovering BIOS:Automatically recover BIOS update once crash happen
- ASUS Event Log:Record activities of system and provides information in BIOS
- ASUS Commercial BIOS kit:Speed up BIOS update solutionby partial BIOS design
- Anti-Moisture:Against moisture and corrosion — prolonging the life of your motherboard
- 24/7 Reliability:Tested under temperature up to 45°C and humidity up to 80% to ensure handle diverse environment
Easy Assembly Design:
- Fixed-position&Color-coded Connectors:Enable easy identification and cable-matching, speeding up the production line
- Box Headers:USB headers are box style, enabling fast connector installation and preventing pin damage
Digi+VRMOperating System SupportWindows® 10Back I/O Ports1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x D-Sub
2 x DisplayPort
1 x HDMI
1 x LAN (RJ45) port(s)
4 x USB 3.1 Gen 2 Type-A
2 x USB 2.0
3 x Audio jack(s)Internal I/O Ports1 x MONO out header *2
2 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only)
1 x LPT header
2 x COM port(s) connector(s)
6 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s) (1 x 4-pin)
2 x Chassis Fan connector(s) (2 x 4-pin)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x Internal speaker connector(s)
1 x System panel(s)
1 x Chassis Intrusion connector(s)
1 x M.2 Socket 1 with E key, type 2230 for Wi-Fi/BT devices support or PCIE/USB mode
1 x LPC Debug headerAccessoriesUser´s manual
I/O Shield
2 x SATA 6Gb/s cable(s)
3 x M.2 Screw Package
1 x Supporting DVDBIOS192Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS smart recovering BIOS, ASUS Event log, ASUS Commercial Kit
